5. SYSTEM COMMAND DETAILS
5.1 Baud rate
STX 05 B n ETX /Set baud rate and keep it with EEPROM/
ASCII Format STX 05 B n ETX
Dec. Format [02][05][66] n [03]
Hex. Format [02h][05h] [42h] n [03h] 30h<n<37h
Description Change the display communication baud rate. The baud rate setting can be selected from 300 to 38400.
The setting function will be saved to EEPROM.
N Baud rate
30h 9600
31h 4800
32h 2400
33h 1200
34h 600
35h 300
36h 38400
37h 19200
5.2 International character set
STX 05 S n ETX Change international character set
ASCII Format STX 05 S n ETX
Dec. Format [02][05][83] n [03]
Hex. Format [02h][05h] [53h] n [03h] 30h<n<3fh
Description Change the display international character font. A total of 16 different character fonts to select from.
The setting function will be saved to EEPROM.
n International font n International font
30h U.S.A 38h JAPAN
31h FRANCE 39h NORWAY
32h GERMANY 3Ah DENMARK II
33h U.K 3Bh SLAVONIC
34h DENMARK I 3Ch RUSSIA
35h SWEDEN 3Dh Factory define
36h ITALY 3Eh Factory define
37h SPAIN 3Fh User define pattern
5.3 Command type select
STX 05 C n ETX Change command type
ASCII Format STX 05 C n ETX
Dec. Format [02][05][67] n [03]
Hex. Format [02h][05h] [43h] n [03h] 30h≦n ≧37h
Description This command will change the command type and initialize the display. The display emulation mode
is based on CD5220II/ESC POS/ADM787/ADM788/ UTC/AEDEX/EMAX mode. The setting function
will be saved to EEPROM.
n Command type n Command type
30h DSP800 34h AEDEX
31h ESC/POS 35h UTC/P
32h ADM788 36h UTC/S
33h ADM787 37h CD5220
