6. COMMAND
6.1 Command list
6.1.1 CD 5220-II STANDARD MODE
Command Code description (hex) Function description
ESC DC1 1B 11 overwrite mode
ESC DC2 1B 12 vertical scroll mode
ESC DC3 1B 13 horizontal scroll mode
ESC Q A ..........CR 1B 51 41 [n ]x20 0D set the string display mode, write string to upper line
ESC Q B ..........CR 1B 51 42 [n ]x20 0D set the string display mode, write string to lower line
ESC Q D ..........CR 1B 51 44 [n ]x20 0D upper line message scroll continuously
ESC [ D 1B 5B 44 move cursor left
BS 08 move cursor left
ESC [ C 1B 5B 43 move cursor right
HT 09 move cursor right
ESC [ A 1B 5B 41 move cursor up
ESC [ B 1B 5B 42 move cursor down
LF 0A move cursor down
ESC [ H 1B 5B 48 move cursor to home position
HOM 0B move cursor to home position
ESC [ L 1B 5B 4C move cursor to left-most position
CR 0D move cursor to left-most position
ESC [ R 1B 5B 52 move cursor to right-most position
ESC [ K 1B 5B 4B move cursor to bottom position
ESC l x y 1B 6C x y
1<x<20,y=1,2
move cursor to specified position
ESC @ 1B 40 initialize display
ESC W s x1 x2 y 1B 57 1 x1 x2 y 1<x1<x2<20
y=1,2
reset window range at horizontal scroll mode
CLR 0C clear display screen, and clear string mode
CAN 18 clear cursor line, and clear string mode
ESC * n 1B 2A n 1<=n<=4 brightness adjustment
ESC & s n m [a(p1..pa)]x
(m-n+!)
1B 26 1 n m [a(p1..pa)]x (m-n+1)
20h<n<=m<=FFh
a=1-5 , p1..p5 =row1..row5
define download characters.
ESC ? 1B 3F delete download characters.
ESC % 1B 25 select/cancel download character set.
ESC _ n 1B 5F n n=0,1 set cursor ON/OFF
ESC f n 1B 66 n select international fonts
ESC c n 1B 63 n select fonts, ASCII code or JIS code
ESC s 1 1B 73 01 store user-define character into EEPROM
ESC d 1 1B 64 01 restore user-define character from EEPROM
ESC = n 1B 3D n
n=3; enable printer, enable display
n=4; message for customer side
(for CD7220D only)
n=5; message for operator side
(for CD7220D only)
default n=2
select peripheral device, display or printer: display for
customer side or display for operator side
Table 6-1
(REMARK)
* While using command "ESC QA" or "ESC QB", these two commands can be used with terminal printer: TP2688 or TP3688
* While using command "ESC QA" or "ESC QB", other commands can not be used except when using command "CLR" or "CAN" to change operating mode.
* When using command "ESC QD", the upper line message will scroll continuously until a new command is received, it will then clear the upper line and
move the cursor to the upper left-end position.
