At each corner of the roof canvas is a ring, to which you can attach a tension strap.
Pull this tight.
You can secure the bottom edges of the side walls using tent pegs in the loops provided for
this purpose. There are also holes in the base plates of the legs for this purpose. You can also
place weights on the base plates.
ANCHORING THE TENT STOWING THE TENT
1. Allow the legs to sink fully by pulling the pin. Do the same as when you set up the tent
but in reverse: either on one short side or one long side of the tent, but never with two
diagonally opposite legs.
2. Undo all the tension straps on the inside of the roof.
3. Free the roof frame by pulling on the pins. It may help to place your foot on the base plate
and push the roof frame slightly upwards.
4. With two people (each on one short side of the tent), push at the top where the two scissor
sections meet towards each other. The tent will fold itself together.
14 15FLEXXUM MANUAL FLEXXUM MANUAL
EN EN
3.
1.
4.
