5. Indication Instruction
1) All the pass code is 4 digit（0-9）.
2) “Start” button : wake up button，the keypad or RFID does not respond
before you press “Start” button.
3) Open/Close：GREEN LED on for 0.2 second, one beep sound for 0.2
second.
4) Successful programming：Melody.
5) Indicate for mistake：RED LED flashes 3 times, 3 beep sounds
6) Low voltage：RED LED blinks 5 times, and beep sounds 5 times.
7) Incorrect pass code or input is beyond 5 digits: see #5, power off，need
to press “Start” button to wake up the keypad.
8) When the input is incomplete, after 5 seconds, see #5，power off .
You need to press “Start” button again to wake up the keypad.
