ANNEX A Beep & LED Table
Beep
LED
Description
1 x short beep
1 x Green
OK
3 x short beep
3 X Red
1)Operation Error
Time over or push more than 6 digit
buttons
3 X short beep
1 X Green & Red
User card expired
4 X short beep
-
Exceed the capacity of Lock info card
5 x short beep
5 x Red & Green
Low battery
Do-Re for 1.5 sec
4 X Red & Green
Forced entry. Latch moved without
proper authentication
3 X Do-Re
-
Latch open failure
Do-Mi-Sol-Pa Melody
1 X Green
Operation card and User card
registration or operation Successful
Correct pin code or pin code change
successful
Do-Mi-So-Pa Melody
3 x Red & Green
Successful connection between front
and bodies.
5 X Do-Re-Mi
6 X Red & Green
3shift or Lock time limit activated
No Beep
Both Green and
Red LED blinks
1) Owner Card is not registered.
2) In case of Shift or Week-day
operation mode, Alarm for shift or Time
due.
No Beep
Red on/off
Owner card is registered, but Master
card is not registered.
No Beep
Green on/off
Owner & Master card are registered, but
User card is not registered in Assigned
Mode.
