Pattfield Ergo Tools PE-12 DD User Manual

EN144 EN 145
To release the battery, press the bat-
tery release switch 6 and slide o the
battery.
2
ATTACH BATTERY
Slide the battery 5 onto the tool until it
clicks into place.
Caution! Only use the tool with the
batteries specified in technical data.
1
ROTATION DIRECTION
To drive in screws or drill, set the rota-
tion direction switch 7 to .
Caution! Wait until the chuck has
stopped rotating before changing
the rotation direction.
1 To loosen screws, set the rotation di-
rection switch 7 to .
2
Adjustm ents
ROTATION SPEED
Set the desired rotation speed on the
gear selector9.
1
st
gear: Screw driving /
Larger diameter drilling
1
2
nd
gear: Smaller diameter drilling
2
FIT BIT OR DRILL
Open the chuck ring1 until the bit/drill
fits into the chuck.
Caution! Lock the tool first by cen-
tering the rotation direction switch.
1 Fit the bit/drill into the chuck 2 and
tighten the chuck ring1 securely. Set
the desired torque at the torque ring8.
Remove the bit/drill by opening the
chuck ring1.
2
TORQUE ADJUSTMENT
Set the desired torque with the torque
ring8. Choose for driving ...
... small screws: 1 - 6
... screws into soft material: 7 - 12
... screws into hard material: 13 - 18
1 When drilling, set the torque ring 8
to drill .
2
2
1
2
1
2
1
2
1.
1.
2.
2.
1
1 2
