III - Safety instructions
This product is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the product by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the product.
1. General power tool safety warnings
WARNING!
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for
future reference. The term "power tool" in the
warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power
tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury.
2. Use personal protective equipment. Always
wear eye protection. Protective equipment such as
dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
3. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting to
power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
9594
10. Keep away from the hot blade. This product
releases high temperature that can cause serious
burns and personal injury.
3. Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
1. Always be alert when using this product, so that
you can recognise and handle risks early. Fast
intervention can prevent serious injury and damage to
property.
2. Switch off and disconnect from the power
supply if there is any malfunction. Have the product
checked by a qualified specialist and repaired, if
necessary, before you put it into operation again.
4. Residual risks
Even if you are operating this product in
accordance with all the safety requirements,
potential risks of injury and damage remain. The
following dangers can arise in connection with the
structure and design of this product:
1. Burns resulting from accidental contact with the hot
blade.
2. Cuts when touching the sharp blade.
WARNING!
This product produces an electromagnetic field
during operation! This field may under some
circumstances interfere with active or passive
medical implants! To reduce the risk of serious or
fatal injury, we recommend persons with medical
implants to consult their doctor and the medical
implant manufacturer before operating this
product!
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust
collection can reduce dust-related hazards.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it was designed.
2. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
3. Disconnect the plug from the power source
and/or the battery pack from the power tool before
making any adjustments, changing accessories, or
storing power tools. Such preventive safety
measures reduce the risk of starting the power tool
accidentally.
4. Store idle power tools out of the reach of
children and do not allow persons unfamiliar with
the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking
into account the working conditions and the work
to be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
Service
1. Have your power tools serviced by a qualified
repair person using only identical replacement
parts. This will ensure that safety of the power tool is
maintained.
2. Hot knife safety warnings
WARNING!
Place the product on its standing surface when
not in use!
1. Be careful when using the product in places where
there are combustible materials.
2. Do not apply to the same place for a long time.
3. Do not use in presence of an explosive atmosphere.
4. Do not use in wet environment or to cut wet
materials.
5. Be aware that heat may be conducted to
combustible materials that are out of sight.
6. Keep the blade upward when the tool lies on the
table during intermission of operating the product.
7. Do not leave the product unattended when it is
connected to the power supply.
8. Keep other people, especially children, as well as
pet out of the working area during operation and
before the work area is cleaned thoroughly.
9. Do not use the product near flammable liquids or in
explosive atmospheres, such as near fumes, gases or
dust. The flameless heat from the product may ignite
the dust or fumes. Remove materials or debris that
may become ignited from work area.
SYMBOLS
On the product, the rating label and within these
instructions you will find among others the following
symbols and abbreviations. Familiarise yourself with
them to reduce hazards like personal injuries and
damage to property.
Caution / Warning.
Read the instruction manual.
Wear eye protection.
Wear respiratory protection.
Wear protective gloves.
Wear safety footwear.
Switch the product off and
disconnect it from the power supply
before assembly, cleaning,
adjustments, maintenance,
storage and transportation.
V~ Volt, (alternating voltage)
mm Millimetre
W Watt
kg Kilogram
Hz Hertz
°C Degree centigrade
s Second
RyyWxx Manufacturing date code; year of
manufacturing (20yy) and week of manufacturing
(Wxx); “R”: Complies with Directive 2002/95/EC on
the restriction of the use of certain hazardous
substances in electrical and electronic equipment.
9796
-- This hot knife KD-8 is designated with a rated input
of 120 Watts. This product is intended for cutting and
separating thermoplastic materials like plastic ropes,
weaving ribbon, plastic foam, sponge etc. The product
is only suitable to make short cuts. It may only be used
in dry environment.
--This product is intended for private domestic use
only, not for any commercial trade use. It must not be
used for any purposes other than those described.
Hot surface!
This product is of protection class II.
That means it is equipped with enhanced
or double insulation.
WARNING!
Always use accessories according to the
intended use!
Observe the technical requirements of
this product (see section Technical
specifications) when purchasing and
using accessories!
Some accessories are very sharp and
become hot during use! Handle them
carefully! Wear safety gloves when
handling accessories in order to avoid
injuries like burns and cuts!
Overview
Attaching
-- Loosen the bolts (9) on the blade support (7) with
the hex key (10) (Fig. 2).
NOTE: It is not necessary to remove the
bolts (9), loosen it is sufficient.
-- Align the blade (6) to the blade support (7). Pay
attention to the sharp edge, it must face downward.
(Fig. 3).
NOTE: The selected blade should not be
longer than 20mm (3/4”) past the thickness
of your workpiece. The foam cools the blade as it
cuts. The exposed portion can overheat and cause
your blade to warp.
-- Slide the blade (6) to the blade support (7) and
then fasten the bolts (9) tightly.
Removing/replacing
-- Loosen the bolts (9) on the blade support with
the hex key (10).
-- Remove the blade (6) from the blade support (7)
and attach a new/other one if required.
WARNING!
During operation fumes will be
generated!
Some fumes and dust are highly
inflammable and explosive! Do not
smoke during operation, keep heat
sources and open flames out of the
working area! Always wear an approved
dust mask to protect yourself against
hazards resulting from fumes and
fine dust!
WARNING!
Always switch the product off, disconnect
it from power supply and let the product
cool down before performing inspection,
maintenance and cleaning work!
Description
Straight blade,
100 mm
Illustration Application
Straight cuts,
for thick foam
Straight blade,
150 mm
(not provided)
Straight cuts,
for thick foam
Groover Blade
and Adaptor
(not provided)
Groove cuts.
The product complies with the applicable
European directives and an evaluation
method of conformity for these directives
was done.
WEEE symbol. Waste electrical
products should not be disposed of
with household waste. Please recycle
where facilities exist. Check with your
Local Authority or local store for
recycling advice.
IV- Intended use
-- The following parts are included with the delivery:
• Hot knife
• Blade (6)
• Hex key (10)
• Wire brush (11)
-- Please check the completeness of the delivery and
ensure that all parts are free from any
transport-related damage or any damage in general.
Please contact the supplier from whom you purchased
the product should there be any parts missing or
damaged.
V- Scope of delivery
-- Unpack all parts and lay them on a flat, stable
surface.
-- Remove all packing materials and shipping devices
if applicable.
-- Make sure the delivery contents are complete and
free of any damage. If you find that parts are missing
or show damage do not use the product but contact
your dealer. Using an incomplete or damaged product
represents a hazard to people and property.
-- Ensure that you have all the accessories and tools
needed for assembly and operation. This also includes
suitable personal protective equipment.
VI- Before use
VII- Operation instructions
1 Unpack
-- With this product different blades can be used
depending on the work being conducted. Please note
that not all shown blades are part of this product.
Purchase blades at your professional dealer.
2 Accessories
9998 101100
VIII- Cleaning
-- Keep the product clean. Remove debris from it after
each use and before storage.
-- Regular and proper cleaning will help ensure safe
use and prolong the life of the product.
-- Inspect the product before each use for worn and
damaged parts. Do not operate it if you find broken
and worn parts.
1 General cleaning
The product can be operated in instant mode only.
-- Switch the product on by pressing the on/off switch
(4) and hold it in position (Fig. 4).
-- Release the on/off switch (4) to switch the product
off.
3 Switching on/off
4 Cutting
WARNING!
Only perform repairs and maintenance
work according to these instructions!
All further works must be performed
by a qualified specialist!
-- Make sure the on/off switch (4) is in its off position.
-- Connect the plug with a suitable socket.
WARNING!
Check the voltage! The voltage must comply
with the information on the rating label!
-- Your product is now ready to be used.
3 Connection to the power supply
This product is equipped with a self-resetable safety
cut-out which will operate to cut off the power supply
to the heating elements if the internal temperature
gets too high. It will reset automatically when the
product has cooled down.
5 Thermal protection
Constant use of this product may result in material
build up on the blade and the brass holders. This
excess polystyrene interferes with the proper electrical
and impairs the performance of the blades. The brass
blade holders and blades can be thoroughly cleaned
with a wire brush (11).
2 Blade
-- Switch the product off, place the product on its
standing surface (1), disconnect it from the power
supply and let it cool down.
-- Check, clean and store the product as described
below.
-- Remove blade from the product and keep for future
use.
6 After use
-- Check the product, its power cord and plug as well
as accessories for damage before each use. Do not
use the product if it is damaged or shows wear.
-- Double check that accessories are properly fixed.
-- Always hold the product by its gripping surface.
Keep the gripping surface dry to ensure safe support.
-- Switch the product off immediately if you are
disturbed while working by other people entering the
working area.
-- Do not overwork yourself. Take regular breaks to
ensure you can concentrate on the work and have full
control over the product.
-- Do not touch the hot blade, or store the product until
the blade has cooled to room temperature. Contact
with the blade could result in personal injury.
-- Place the product on its standing surface in a clear
area away from combustible materials while cooling
down to prevent materials from igniting.
-- Work in a well ventilated area. Proper ventilation will
reduce the risk of inhaling chemicals found in the
fumes or dust created by using this product.
-- Be careful when working until the proper
combination of heat and working speed of application
has been obtained. Pausing or lingering in one spot
may ignite or melt the workpiece or the material
behind it.
1 General operation
IX- Storage and transportation
-- Clean the product as described above.
-- Store the product and its accessories in a dry,
frost-free place.
-- For storage it is possible to hang the product on up
its storage hook (Fig. 7). Ensure that the blade is
cooled down and take blades apart from the tool and
the power cord does not contact the sharp blade.
-- Always store the product in a place that is
inaccessible to children. The ideal storage
temperature is between 10 and 30°C.
-- We recommend using the original package for
storage or covering the product with a suitable cloth to
protect it against dust.
1 Storage
X- Maintenance and repair
-- If the power cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a safety hazard.
1 Power cord
-- Switch the product off and disconnect it from power
supply before transporting it anywhere.
-- Attach transportation guards, if applicable.
-- Always carry the product on its handle.
-- Protect the product from any heavy impact or strong
vibrations which may occur during transportation in
vehicles.
-- Secure the product to prevent it from slipping or
falling over.
2 Transportation
2 Hot knife operation
WARNING!
When using the product for a longer period of
time, we recommend using the product in
short time operation (15 seconds on/45 seconds off)!
-- Switch the product on and wait for about 15 seconds
for the blade to get hot.
-- Lead the hot blade through the workpiece. Move the
blade forward at an even speed (Fig. 5).
-- Keep the product moving at all times, do not stop in
one position to avoid burns and melting.
NOTE: If smoke develops during the cut, you
are cutting too slow which results in an
oversized, uneven could cut. This can be remedied by
intermittently releasing the on/off switch during your
cut. As the cutting resistance increases, depress the
on/off switch again. The product will reach a hot
temperature within seconds. You can accomplish your
cut with minimal smoke using this process. Cutting in
this manner will also prolong the life of the product.
-- Release the on/off switch approximately one or tow
inches prior to the completion of the cut to keep the
blade clean and free from build up.
-- Switch the product off and disconnect it from power
supply if the blade is stuck in the workpiece. Only then
free the jammed blade.
WARNING!
Place the product on its standing surface (1)
when interrupting the work with the knife facing
upward (Fig. 6).
-- Clean the product with a dry cloth. Use a brush for
areas that are hard to reach.
-- Remove stubborn dirt with high pressure air (max. 3
bar).
NOTE: Do not use chemical, alkaline,
abrasive or other aggressive detergents or
disinfectants to clean this product as they might be
harmful to its surfaces.
-- Check for worn or damaged parts. Replace worn
parts as necessary or contact an authorised service
centre for repair before using the product again.
-- Old products are potentially recyclable and do not,
therefore, belong in your household rubbish. You are
requested to assist us and our contribution to saving
resources and protecting the environment by handing
in this product at an equipped collection centre (if
there is one available).
-- The product comes in a package that protects it
against damages during shipping. Keep the package
until you are sure that all parts have been delivered
and the product is function properly. Recycle the
package afterwards.
XII- Recycling and disposal
Dear Customer, our products undergo strict quality
controls. In the case of malfunction, which point to
material or workmanship, please contact your
Hornbach-Baumarkt.
For any warranty claims:
1) These conditions cover additional guarantee and
are free for you. The statutory warranty claims
remain unaffected.
2) The warranty is limited to material or
manufacturing defects and their repair or
replacement of the device. Since our devices are
not designed for use in commercial, trade or
industrial applications, is the guarantee contract is
not concluded, if it is used in these or other
equivalent activities. It also excludes compensation
for damage, damage by not following the installation
or use instructions (e.g connecting to the wrong
voltage or current), improper installation, misuse or
improper use (such as overloading of the equipment
or use of unauthorized tools or accessories) ,
neglect of maintenance and safety regulations,
penetration of foreign objects into the device (such
as sand, stones or dust), use of force or external
influences (such as damage from being dropped)
and with use of modern, normal wear (such as
batteries, knives, etc.). The warranty is voidif the
device is made to tamper.
3) The guarantee period is 3 years from the date of
purchase of the equipment. Warranty claims must
be made within the warranty period and within two
weeks of the perception of the defect. A later claim
is excluded. By the repair or replacement of the
device, the guarantee period is extended or a new
warranty for the equipment or any replacement parts
in motion.
4) To guarantee payment of damages, please
contact your Hornbach-Baumarkt and present the
original sales receipt or other dated proof of
purchase. Keep the receipt so well!Describe the
problem in as accurately as possible. If the defect is
covered by our warranty service, you will
immediately receive a repaired or new equipment.
XIII- Guarantee
-- This product does not contain any parts that can be
repaired by the consumer. Contact a qualified
specialist to have it checked and repaired.
Suspected malfunctions are often due to causes that
the users can fix themselves. Therefore check the
product using this section. In most cases the problem
can be solved quickly.
WARNING!
Only perform the steps described within these
instructions! All further inspection, maintenance and
repair work must be performed by an authorised
service centre or a similarly qualified specialist if you
cannot solve the problem yourself!
2 Repair
XI- Troubleshooting
Problem Possible cause Solution
1. Product does
not start
1.1 Not connected
to power supply
1.2 Power cord or
plug is defective
1.3 Other electrical
defect to the product
1.1. Connect to
power supply
1.2. Check by a
specialist electrician.
1.3. Check by a
specialist electrician
2. Product does
not reach full
power
2.1 Extension cord
not suitable for
operation with this
product
2.2 Power source
(e.g. generator) has
too low voltage
2.3 Air vents are blocked
2.1. Use a proper
extension cord
2.2. Connect to
another power source
2.3. Clean the air vents
3. Unsatisfactory
result
3.1 Blade not suitable
for workpiece material
3.2 Blade dump
3.1. Use proper
blade
3.2 Replace with
a new one
XIV- EC Declaration of conformity
Made for HB Services GmbH Hornbachstrasse 76879 Bornheim / Germany
We hereby declare that the product
HOT KNIFE 120W KD-8
• Low Voltage Directive 2006/95/EC
• EMC Directive 2004/108/EC
Bornheim, den 03.07.2012
So that it conforms to the following applicable harmonized standards:
Andreas Back
Leiter Qualitätsmanagement
EN55014-1/A1:2009
EN55014-2/A2:2008
EN61000-3-2/A2:2009
EN61000-3-3:2008
EN 60335-1/A14:2010
EN 60335-2-45/A1:2008
EN 62233:2008
XIV- Declaraţie de conformitate
Prin prezenta, declarăm faptul, că produsul
CUŢIT FIERBINTE 120W KD-8
• Directiva 2006/95/CE privind aparatele de joasă tensiune
• Directiva 2004/108/CE Referitoare la Compatibilitatea
Electromagnetică
Bornheim, den 03.07.2012
şi conform prevederilor următoarelor norme armonizate
care urmează a fi aplicate:
Andreas Back
Leiter Qualitätsmanagement
EN55014-1/A1:2009
EN55014-2/A2:2008
EN61000-3-2/A2:2009
EN61000-3-3:2008
EN 60335-1/A14:2010
EN 60335-2-45/A1:2008
EN 62233:2008
Fabricat pentru HB-Services GmbH, 76879 Bornheim, Germania
To Previous Page
Loading...
Need help?
General
