Patton Kamado - Page 24

24
FR, CH
ÉTAPE 6 -Conrmerlapoignée(5)dugrilkamadoaumoyendeboulonspré-attachésetécrousborgnes.
Le cuiseur Kamado est maintenant prêt à l’emploi, mais veuillez vous assurer d’avoir lu ces instructions attentivement
avant de l’utiliser.
8
Assembly instructions
STEP 6 - To attach the handle (5) to the lid of the Kamado grill(9).start by aligning the bolt holes of the handle to
pre-installed bolts on the lid. Secure the handle (5) with the 2x pre-attached dome headed nuts.
B.
5.
9.
8
Assembly instructions
STEP 6 - To attach the handle (5) to the lid of the Kamado grill(9).start by aligning the bolt holes of the handle to
pre-installed bolts on the lid. Secure the handle (5) with the 2x pre-attached dome headed nuts.
B.
5.
9.
