6 Spare parts [specialist]
16 9976x0210x-mub-en – V01 2020/09
Position
Spare part
Item number
1
Return ball valve DN 20,
¾" int. thread x F ¾" x ¾" ext. thread on the right, solar check valve
N00290
2 Solar pressure relief valve ½" x ¾", MSV 6 bars N00300
3
Pressure gauge 0-6 bars / 0-90 psi,
with automatic isolation ⅜" ext. thread, d = 50 mm, 130°C
N00301
4 Dial thermometer, blue scale, d = 50 mm, 0-160 °C N00194
5
Alternative pumps:
Wilo Para ST 15/7 N00150
Wilo Para ST 15/13 N00299
Grundfos UPM3 Solar 15-75 N00025
Grundfos UPM3 Solar 15-145 N00215
6
Flow meter ¾", 3-22 l/min, DN 20,
1" M x ¾" int. thread x ½" int. thread, with fill and drain valve
N00225
7 Sealing kit consisting of 10 pieces, ½", for thread connection 1" N00024
8 Union nut G 1", passage 28.1 mm, wrench size 37, octagonal N00302
Not
shown in
drawing
Pump cable for Wilo Para ST, 2 m N00152
Pump cable for Grundfos UPM3 Solar N00199
PWM connection cable for Wilo Para ST, 2 m, U < 24 V N00342
PWM connection cable for Grundfos UPM3 Solar N00372
Connection of the high-efficiency pumps
Wilo Para ST 15/7
Wilo Para ST 15/13
Grundfos UPM3 Solar 15-75
Grundfos UPM3 Solar 15-145
PWM
Brown
GND
Blue
