2. Device Layout
Front and side views



Component Description
MIC AudioRecordingDevice
FrontCamera RecordStillandVideoImages
ChargeLEDIndicator WhiteBlinkingLight–BatteryCharging
SolidGreen–ChargeComplete
RedBlinkingLight–LowBattery(BatteryBelow10%)
MIC AudioRecordingDevice
Speaker SendsOutAudio
Lock Forlockingtabletinassociatedwallcharger.WhenitisunderLock
mode,thetabletcannotbetakenoutfromthewallcharger.
DockingConnector ConnectsthetabletwiththeTabletDockingStation
Headset Connectheadphone
TelephoneReceiver Handsetfunctionforvoicecalls
Volume+Button Increasestheaudiovolume
Volume‐Button Decreasestheaudiovolume
PowerButton TurnpowerOn/Off(Hold10stoReset)
