Connector Type 4 x F type female 75Ω
Input Frequency Range
48~860MHz
Input Level
45 75dBµV
Symbol Rate
1 7MBauds ITU J.83 Anne× A
Constellation 16/32/64/128/256QAM
Bandwidth 6MHz/7MHz/8MHz
Return Loss 7dB
DVB-T/T2 Tuner Input
Connector Type 4 x F type female 75Ω
Input Frequency 104~862MHz (VHF/UHF)
Input Level -20 ~ -70dBm
Constellation DVB-T: QPSK, 16QAM, 64QAM
DVB-T2: QPSK, 16QAM, 64QAM, 256QAM
Bandwidth 6MHz/7MHz/8MHz
FFT Mode DVB-T: 2K/8K
DVB-T2: 1K, 2K, 4K, 8K, 16K, 32K
Guard Interval DVB-T: 1/4, 1/8, 1/16, 1/32
DVB-T2: 1/4, 5/32, 1/8, 5/64, 1/16, 1/32, 1/64, 1/128
FEC Code Rate DVB-T: 1/2, 2/3, 3/4, 5/6, 7/8
DVB-T2: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6
Return Loss 7dB (typ.)
ASI Output
Connector Type 4 x BNC female, 75Ω
Standard DVB-ASI, EN50083-9
Output Bit Rate ≤108Mb/s
TS over IP
Connector Type 1 x RJ-45, 100/1000 Base-T
Protocol UDP/RTP, Multicast/Unicast, IGMP V2/V3
Operation Mode
1. Simplex DVB output mode, total 5 DVB MPTS streams, 4 from Tuners, 1 from
internal reMUX
2. Simplex IPTV out mode, total 128 Program streams(for IP applications, no
stuffing/null packet, non DVB standard), from any one of 4 tuners or from internal
reMUX.
3. Full Duplex DVB mode, 1 DVB MPTS streams input and 1 DVB MPTS streams
output
Note: Please follow the User Manual to configurate these modes.
Effective Bit Rate
1. Simplex DVB out mode: 700Mb/s Max.
2. Simplex IPTV out mode: 550Mb/s Max.
3. Full Duplex DVB mode, Input: 80Mb/s Max., Output: 80Mb/s Max.
Control & Monitoring
Connector Type 1×RJ-45, 10/100 Base-T, for equipment IP Control
Remote Control SNMP, HTTP (Web Interface), Proprietary HDMS (Headend Device Management
System)
