PCE Instruments PCE-DC 3 - Features; Specifications; General Specifications; Range Specifications

1. Features
• High resolution to 1mA AC
• 3-2/3 digit (2400 count) LCD display
• White LED backlight
• Built-in non-contact AC voltage detector plus flashlight
• Autoranging with auto power off
• 0.7” (18mm) Jaw opening
2. Specifications
z General Specifications
Display 3-2/3 (2400 count) Digit LCD with white LED backlight
Polarity Minus sign ( - ) indicates negative polarity
Current sensor Hall effect sensor type
Overload indication “OL” displayed on the LCD
DCA zero adjust One touch zero key
Display rate 2 readings/second, nominal
Battery Two 1.5V AAA batteries
Low Battery indication “BATT” displayed on the LCD
Auto OFF approx. 7 minutes
Operating conditions 32
º
F to 86
º
F (0
º
C to 30
º
C) 90%RH; 86
º
F to 104
º
F (30
º
C to 40
º
C) 75%RH; 104
º
F to 122
º
F
(40
º
C to 50
º
C) 45%RH
Storage conditions - 14
º
F to 140
º
F (-30
º
C to 60
º
C); < 90% Relative Humidity
Altitude Operate at less than 3000 meters
Weight 6.2 oz. (175g) including battery
Dimensions 164 x 65 x 32mm (6.5 x 2.6 x 1.3”) (HXWXD)
Jaw opening 18mm (0.7”)
Standards EN61010-1, EN61010-2-032 Category II 600V, Category III 300V
z Range Specifications
Function Range Resolution Accuracy (of reading)
DC Current
2A 1mA ± (2.8% + 10 digits)
80A 100mA ±(3.0% + 8digits)
AC Current (50/60Hz)
2A 1mA ±(3.0% + 10 digits)
80A 100mA ±(3.0% + 8 digits)
Non-Contact AC Voltage
100VAC to 600VAC 50/60Hz
3. Meter Description
1. Current sense jaw
2. Flashlight button
3. Rotary function switch
4. Data HOLD and Backlight key
5. LCD display
6. Clamp trigger
7. One-touch DCA ZERO key
8. Non-contact AC voltage indicator light
9. Non-contact AC voltage detector probe tip
