57
L510010-07A
ENGINE SPECIFICATIONS - 12
MODEL MP 5.0L MP 5.7L MP 6.0L
(Horsepower) (275 HP) (343 HP) (390 HP)
Fuel Pressure 57-62 psi @ WOT 57-62 psi @ WOT
STD. FCC
Fuel Pressure - FCC 57-62 psi
Returnless to Rail (WOT)
Fuel Pressure - LPFP 7 - 9 psi 7 - 9 psi 7 - 9 psi
ALL ENGINES (WOT) (WOT) (WOT)
PCM MASTER FUEL PRESSURE SPECIFICATIONS - 2007
IMPORTANT: FUEL PRESSURE MEASUREMENT MUST BE MADE WITH THE
ENGINE UNDER LOAD.
MODEL MP 5.0L MP 5.7L MP 6.0L
(Horsepower) (275 HP) (343 HP) (390 HP)
Coolant 220° F (104.8° C) 220° F (104.8° C) 220° F (104.8° C)
Over-Temperature M.I.L. - DTC 116 M.I.L. - DTC 116 M.I.L. - DTC 116
Sensor Check Engine Lamp Check Engine Lamp Check Engine Lamp
and/or Buzzer and/or Buzzer and/or Buzzer
Transmission 235° F ± 10° F 235° F ± 10° F 235° F ± 10° F
Over-Temperature M.I.L. - DTC 1542 M.I.L. - DTC 1542 M.I.L. - DTC 1542
Switch Check Engine Lamp Check Engine Lamp Check Engine Lamp
Exhaust 248° F ± 5° F 248° F ± 5° F 248° F ± 5° F
Over-Temperature M.I.L. - DTC 2428 M.I.L. - DTC 2428 M.I.L. - DTC 2428
Switch Check Engine Lamp Check Engine Lamp Check Engine Lamp
and/or Buzzer and/or Buzzer and/or Buzzer
Low Oil < 10 psi < 10 psi < 10 psi
Pressure Sensor M.I.L. - DTC 524 M.I.L. - DTC 524 M.I.L. - DTC 524
Check Engine Lamp Check Engine Lamp Check Engine Lamp
and/or Buzzer and/or Buzzer and/or Buzzer
PCM MASTER WARNING/ALARM SPECIFICATIONS - 2007
