PEACOCK IBIS - Dimensions; Package Contents; Ceiling Mounting Bracket; Ball;Downrod Assembly

IBIS CEILING FAN LED
Installation Manual
REV 2022 1115
SPECIFICATIONS AND DETAILS ARE SUBJECT TO CHANGE WITHOUT NOTIFICATION. CONTACT PEACOCK FAN COMPANY FOR UP TO DATE DETAILS.
PEACOCK FAN COMPANY • PEACOCKFAN.COM
SAVE THESE INSTRUCTIONS
2
DIMENSIONS
PACKAGE PARTS
TOOLS AND MATERIALS REQUIRED
6.5”
52.65”
12”
5.9”
9.4”
• Philips Screw Driver
• Flat Head Screw Driver
• 11 mm Wrench
• Step Ladder
• Wire Cutters
A) Ceiling Mounting Bracket
B) Ball/Downrod Assembly
C) Canopy
D) Joint cover
E) Fan Motor Assembly
F) Decorative covers
G) The fan blades (4)
H) A set of controllers
I) Fasteners Package
1. Mount Hardware
• Flat Washer (4)
• Wood Screw (4)
• Spring Pad (4)
• Star Washer (2)
• Screw (2)
• Fan blade set screw (13)
• Red gasket (23)
2. Balance Kit
IMPORTANT REMINDER: You must use
the parts provided with this fan for proper
installation and safety.
A
B
C
D
E
F
G
H
I
