IBIS CEILING FAN LED
Installation Manual
REV 2022 1115
SPECIFICATIONS AND DETAILS ARE SUBJECT TO CHANGE WITHOUT NOTIFICATION. CONTACT PEACOCK FAN COMPANY FOR UP TO DATE DETAILS.
PEACOCK FAN COMPANY • PEACOCKFAN.COM
SAVE THESE INSTRUCTIONS
4
SCHEMATIC DIAGRAM OF THE WHOLE MACHINE INSTALLATION
Screws
Canopy
Rotating
Retaining Clip
Screw
Red gasket
Fan body
The fan blade
Installing Fan Blades
Fan body
Decorative covers
Screws
Hitch pin
Coupling cover
Drop Ball Connection Diagram
Locating slot
Canopy Installation
(Connect the receiver and wire according to Figure 5 on Page 5, then lock the screw)
