4. Using the sensor mounting kit, follow these steps:
15 Peak M1 Nighthawk Installation Manual
a. Begin by pushing out the centre holes of the base plate. Position the sensor, then
secure the backing plate using the supplied screws.
b. Apply the adhesion promoter generously
to the base of the sensor bracket (the
side that will face upward against the
bar) and also around the sensor hole
cutout in the bar.
