3. Moving to the front wheel arch,
remove screws from the inner
splash guard on the bumper
portion down the inside of the
wheel arch and underneath.
Repeat for other side.
2. Remove screws a top of the grill.
(Under cowling).
4. Locate the hole in the splash
guard where the quarter panel
and the bumper meet. Using a
Philips head, remove the vertically
positioned retainer screw.
Repeat for other side.
Peak M1 Nighthawk Installation Manual 08
5. Remove factory bash plates.
To Next Page
