6. Once all screws are removed pull bumper off starting from one side. Once
bar releases itself, keep close as the wiring harness is still connected.
Unclip the front bar wiring loom connection located on the passenger
side. Remove the front bar from the front of the car and place on a stand.
7. Once bumper bar is removed from the vehicle unclip wiring harness from
the bar and set aside.
9. Unbolt power steering cooler
lines from center reinforcement.
10. Unbolt and remove center
reinforcement.
8. Using a Phillips head screwdriver remove plastic bumper retaining
brackets from the quarter panels on both sides.
B
09 Peak M1 Nighthawk Installation Manual
