PeakTech 3355 - Page 12

Duty cycle
Model
Range
Resolution
Accuracy
P 3355 0,1...99,9 % 0,1%
±
1,2% rdg. +2 dgt.
Pulse width: >100 µs,< 100 ms
Frequency: 5Hz-150kHz
Sensitivity: <0,5V
rms
P 3360 0,1...99,9 % 0,01% +/- 1,2% rdg. +2 dgt.
4-20mA%
-25...125%
0,01%
+/-50 dgt.
0 mA = -25%; 4 mA = 0 %;
20 mA = 100 %, 24 mA = 125 %
Pulse width: >100 µs,< 100 ms
Frequency: 5Hz-150kHz
Sensitivity: <0,5V
rms
Overload protection: 600 V DC/AC
rms
Temperature
Model
Range
Resolution
Accuracy
P 3355 -20 ... +760°C 1°C
±
3,0% rdg. + 3,0°C
-4...+1400°F 1°F
±
3,0% rdg. + 3,0°F.
P 3360 -50...+1000°C 1°C
±
1,0% rdg. + 2,5°C
-58...+1832°F 1°F
±
1,0% rdg. + 4,5°F
Overload protection: 600 V DC/AC
rms
Temperature Accuracy : Probe accuracy not included.
-44-
