AC True RMS or current
(P3445 only)
The term stands for “Root-Mean-
Square,” which represents the
method of calculation of the voltage
value. Average responding
multimeters are calibrated to read
correctly only on sine waves and
they will read inaccurately on non-
sine wave or distorted signals. True
rms meters read accurately on either
type of signal.
“ ” is displayed if battery voltage
drops below operating voltage
mA, μA ranges:
0.8A/1000V (6,3x32mm) ceramic
fast blow A-range: 10A/1000V
(10x32mm) ceramic fast blow
This meter is intended for origin of
installation use and protected,
against the users, by double
insulation per EN61010-1 and
IEC61010-1 2
nd
Edition (2001) to
Category IV 600V and Category III
1000V; Pollution Degree 2. The
meter also meets UL 61010-1, 2
nd
Edition (2004), CAN/CSA C22.2 No.
61010-1 2
nd
Edition (2004), and UL
61010B-2-031, 1st Edition (2003)
