Note:
* When transistor measurement has been completed,
disconnect the connection between the testing clips and
the circuit under test and remove the testing clips away
from the input terminals of the Meter.
6. Maintenance of the unit
WARNING !
Remove all the test leads before changing battery.
6.1. Battery Replacement
WARNING !
To avoid false readings, which could lead to possible electric
shock or personal injury, replace the battery as soon as the
battery indicator “ “appears.
To replace the battery:
1. Turn the Meter power off and remove all connections from
the terminals.
2. Remove the screw from the battery compartment, and
separate the battery compartment from the case bottom.
3. Remove the battery from the battery compartment.
4. Replace the battery with a new 9V battery (NEDA 1604,
6F22 or 006P)
-31-
