2. Power Switch
Use this switch to turn the unit on and off. Place the switch in the ÒIÓ position to turn the unit on and
ÒOÓ position to turn the unit off.
3. Fuse
The fuse is located within the cap of the fuseholder. If the fuse should fail, IT MUST BE
REPLACED WITH THE SAME TYPE AND VALUE IN ORDER TO AVOID DAMAGE TO THE
EQUIPMENT AND TO PREVENT VOIDING THE WARRANTY. If the amp repeatedly blows, it
should be taken to a qualified service center for repair. WARNING: THE FUSE SHOULD
ONLY BE REPLACED WHEN THE POWER CORD HAS BEEN DISCONNECTED FROM ITS
POWER SOURCE.
4. Parallel Line Inputs
These two jacks are provided to supply a single input signal to the 112 PM and to allow for daisy-
chaining the signal to possibly another 112 PM or amp/monitor combination. Do not attempt to apply
two different signals to the Parallel Line Inputs. Use the second jack only as a parallel output to
another unit.
5. Full Range Output
The Full Range Output is a post EQ, powered output. Designed for a minimum impedance of 8
ohms, this output should be connected only to non-powered monitor enclosures. The Peavey 112M
is the perfect extension monitor to use in this application.
6. Four-Band Graphic EQ
Use this Four-Band Graphic EQ to cut or boost your signal up to 12 dB at the designated frequency
centers. This is especially useful for reducing low frequency rumble or feedback that often occurs on
stage.
7. Level
The Level control adjusts the overall volume of the amplified signal. Therefore, by adjusting the
Level control of the 112 PM you also adjust the level of any monitor(s) connected to the Full Range
Output (5).
4
