Peavey 112 PM User Manual

Amplifier Specifications
Rated Power (120V AC, 60 Hz):
75W into 8 ohms
Input Impedance:
Greater than 33K ohms
Frequency Response:
+0, -1 dB 30 Hz to 30K Hz
Total Harmonic Distortion:
Typically below .1%
Sensitivity:
1V RMS for full rated power output
EQ:
+, - 12 dB cut and boost
Speaker System Specifications
Frequency Response:
100 Hz to 17k Hz
Sensitivity (1 Watt at 1 Meter):
96 dB SPL
Weight:
40 lbs.
Dimensions:
14.63" H x 22.50" W x 17.75" D
37.15 cm x 57.15 cm x 45.09 cm
112 PM
ª
Powered Floor Monitor
Specifications
5
Mon. Line
Output
XR
¨
560
112 PM
ª
Second
112 PM
ª
(optional)
112m
ª
(optional)
112 PM
ª
HOOK-UP DIAGRAM

Peavey 112 PM Specifications

General

Brand	Peavey
Model	112 PM
Category	Speakers
Language	English
