12
Preamp Input:
Impedance: 1 ohms
Nominal Sensitivity (Rhythm): -32.8dBV, 23.0m (rMS)
Nominal Sensitivity (Lead): -63.5dBV, 667uV (rms)
Crunch Boost (Clean channel only):
Increased gain and altered reponse for very brown voicing.
Equalization (both channels)
Custom Low, Mid & High EQ.
Effects Return:
Load Impedance: 22k ohms or greater
Nominal Output Level: -3.0dBV, 0.7V (rms)
(MSDI
™
) Microphone Simulated Direct Interface:
Load Impedance: 6k ohms or greater
Nominal Output Level: -29.1dBV, 35.0V (rms)
Remote Footswitch: (optional)
Special two-button unit with LED indicators (not included,
Peavey #00592720) for channel selection (Channel) and
remote activation of the Crunch boost (BOOST).
6505+
®
112 Combo Specications
NOTE: The following specifications were measured with all preamp controls set at "5"
(Crunch "out"); Post Gains set at "10," Reverb, Resonance and Presence all set at "0."
Preamp Specifications
Rated Power & Load:
60 W(rms) into 4, 8, or 16 Ω
(selectable)
Power Consumption:
150 W, 60 Hz, 120 VAC (Domestic)
150 W, 50/60 Hz, 220-240 VAC (Export)
Tube Complement:
2 x 6L6GC, 5 x 12AX7/ECC83
Dimensions (H x W x D):
22.3"(567mm) x 25.5" (648mm) x 11.2" (285mm)
Weight:
64.2 lbs. (29.1 kg)
6505+ 112 Combo
NOTE: Specifications subject to change without notice.
