23
Crosstalk/Attenuation
Adjacent Input Channels (1 kHz) -70 dB typical Mute Button Attenuation (1 kHz) -80 dB typical
Left to Right Outputs (1 kHz) -70 dB typical Channel Fader Kill (1 kHz) -80 dB typical
Weight
Power Requirements
16FX dosmetic: 120 VAC 60 Hz 50 watts nominal
16FX export: 230 VAC 50/60 Hz 50 watts nominal
24FX: 100-240 VAC 50/60 Hz 60 watts nominal
32FX: 100-240 VAC 50/60 Hz 70 watts nominal
16FX: 22 lbs. (10.0 kg)
24FX: 25 lbs (11.4 kg)
32FX: 30 lbs. (30.0 kg)
Installation Note, Ventilation:
This unit must have the following clearances from any combustible surface: top: 8", sides: 12", back: 12"
Dimensions
16FX: 7.25"h x 19.0"w x 18.0"d on table top
16.7" wide without rack ears
(18.4cm x 48.3cm x 45.7cm on table top)
(42.4cm wide without rack ears)
10RU (17.44") x 19.0" x 7.25" in equipment rack;
6.75" behind rack
(44.3cm x 48.3cm x 18.4cm in equipment rack)
(17.1cm behind rack)
24FX: 7.75" high x 24.4" wide x 18.8" deep
(19.7cm x 619cm x 47.7cm)
32FX: 7.75" high x 32.5" wide x 18.8" deep
(19.7cm x 82.6cm x 47.7cm)
Phantom Power
Signal/Clip Indicators
Yellow: -30 dBu Red: 2 dB below clipping
+48 volts
Equivalent Input Noise (EIN)
-129 dBu (Mic input terminated with 150 Ohms)
Common Mode Rejection Ratio (Mic Input)
-50 dB minimum (20 Hz to 20 kHz)
-60 dB typical @ 1 kHz
16FX
™
,
24FX
™
and 32FX
™
Specifications
Test Conditions: 120 VAC 60 Hz maintained throughout testing
