4
To prevent injury DO NOT place heavy items on top of unit.
Clear the dust out from the inside regularly. Accumulated dust can create a fire hazard
as well as damage to the equipment.
Clear the dust out from plug and AC outlet. Again this accumulated dust can create a fire
hazard.
Make sure the AC/DC adapter is plugged in entirely. No exposed metal.
When not in use for long periods of time, turn unit off and remove the AC adapter.
This booklet gives instructions for the operation of the PV-1 VHF wireless,
including handheld, instrument, lavalier, headset and plug-in transmitter systems.
Please read the instructions for your system completely before operating unit.
This manual will first list the features of the PV-1 and then will take you step by
step on how to operate your system. After reading the receiver instructions, turn
to the section of the booklet that covers the type of transmitter used with your
system. Each section will give you detailed operating instructions. Also included
in this manual are system specifications and servicing information.
• Available on selected frequencies in the VHF band for long range performance
• Proprietary compander circuitry for an industry-best 120dB Dynamic Range, and the clearest, most
natural sound available
• Operating Range: Up to 250 feet typical (depending on site conditions)- 500+ feet line-of site
• Noise-free transmitter ON-OFF operation
PV-1 RECEIVER
• Half-rack receiver design with retractable front panel dual antennas
• Proprietary diversity digital processing circuitry to eliminate dropouts and maximize operating range
• RF and AF 4-LED displays for monitoring incoming signal strength and audio level
• Balanced XLR and unbalanced adjustable ¼” jack outputs
• Mute (squelch) adjust control
• Externally powered by AC/DC power adapter
• Unique snap-out panel locking tabs for single receiver or dual receiver (side-by-side) optional rack
mounting kits available
