15
Output
Master Left/Right
Monitor Send
Effects Sends
Residual Noise
-97 dBu
-90 dBu
-83 dBu
-95 dBu
-80 dBu
-100 dBu
-80 dBu
S/N Ratio (Ref: +4 dBu)
101 dB
94 dB
87 dB
99 dB
84 dB
104 dB
84 dB
Test Conditions
Master Fader Down‚ Channel Levels Down
Master Fader Nominal‚ Channel Levels Down
Master Fader Nominal, Channel Faders Nominal,
Panned Odd Channels (left), Even Channels (right)
All controls off
All channel sends nominal, masters nominal
All controls off
All channel sends nominal, masters nominal
(Hum and noise measurements: 22 Hz to 22 kHz BW)
Frequency Response
Mic Input to Left/Right Output 14 Hz to 25 kHz +0 dB/-1 dB
Total Harmonic Distortion
<0.02% 20 Hz to 20 kHz Mic to Left/Right Output (10 Hz to 80 kHz BW)
<0.005% Typical (22 Hz to 22 kHz BW)
<0.0007% Mic Pre-amp Distortion
Equivalent Input Noise (EIN)
-129 dBu (input terminated with 150 Ohms)
Crosstalk/Attenuation
Adjacent Input Channels (1 kHz) >90 dB Mute Button Attenuation (1 kHz) >90 dB
Left to Right Outputs (1 kHz) >75 dB Channel Fader Kill (1 kHz) >85 dB
Common Mode Rejection Ratio (Mic Input)
50 dB minimum (20 Hz to 20 kHz)
70 dB typical @ 1 kHz
Meters
8 segment, peak reading (0 dB = +4 dBu)
Signal/Overload Indicators
Red LED lights 3 dB below clipping
Dimensions
PV 10: 12.125" wide x 14.75" deep x 3.5" high (30.80cm x 37.47cm x 8.89cm)
PV 14: 16.125" wide x 14.75" deep x 3.5" high (40.96cm x 37.47cm x 8.89cm)
Installation Note:
This unit must have the following clearances from any combustible surface: top: 8", sides: 12", back: 12"
Weight
PV 10: 9.3 lbs. (4.22 kg)
PV 14: 12.1 lbs. (5.49kg)
Power Requirements
PV 10: 100-240 VAC 50/60 Hz 13 Watts
PV 14: 100-240 VAC 50/60 Hz 17 Watts
Hum and Noise
