Peavey PV6 User Manual

Crosstalk/Attenuation
Dimensions
Meters
Weight
Signal/Overload Indicators
Power Requirements
Common Mode Rejection Ratio (Mic Input)
Adjacent Input Channels (1 kHz) >90 dB
Left to Right Outputs (1 kHz) >70 dB Channel level control Kill (1 kHz) >85 dB
7.25" wide x 11.4" deep x 2.1875" high
(18.42 cm x 28.96 cm x 5.56 cm)
PV6: 3.99 lbs (1.81 kg) 100-240 VAC 50/60 Hz 15 Watts
PV6BT: 4.06 lbs (1.84 kg)
6 segment, peak reading (top green LED = +4 dBu) Red LED lights 5 dB below clipping
50 dB minimum (20 Hz to 20 kHz)
70 dB typical @ 1 kHz
Installation Note:
This unit must have the following clearances from any combustible surface: top: 8", sides: 12", back: 12"

Peavey PV6 Specifications

General

Type	Analog
Channels	6
Mic Inputs	2
Microphone Preamps	2
Line Inputs	4
Inputs - Other	2 x RCA
Outputs - Other	2 x RCA
EQ Bands	2-band
Aux Sends	1
Phantom Power	Yes
USB Interface	No
USB Interface Presence	No
Headphone Output	Yes
EQ Bands per Channel	2
Aux Sends Type	Post
