17
RQ
4324 and 4332 Sound Reinforcement Mixer
Specifications:
Input Specifications:
Function Input Z Input Input Levels Bal./ Connector
(Ohms) gain Min.** Nominal Max. Unbal.
Min. setting
Microphone 2 k Max. Gain -74 dBu -54 dBu -38 dBu Bal. XLR Pin:
(150 Ohms) (58 dB) Pin 1 (Ground)
Pin 2 (+),
Min. Gain -24 dBu -6 dBu +12 dBu Pin 3 (-)
(10 dB)
Line Input 10 k Max. Gain -54 dBu -34 dBu -18 dBu Bal. 1/4" TRS:
(10 k Ohms) (38 dB) Tip (+),
Ring (-),
Min Gain -6 dBu +14 dBu +32 dBu Sleeve (Ground)
(-10 dB)
Insert 22 k N/A -16 dBu +4 dBu +22 dBu Unbal. 1/4" TRS:
Return (0 dB) Tip Send,
Ring Return
Sleeve Ground
Stereo 20 k Max. Gain -29 dBu -9 dBu +4 dBu Unbal. 1/4" Phono
Line Input (20 dB)
Sleeve (Ground)
(RCAs) Min. Gain -16 dBu +4 dBu +18 dBu
0 dB
(detent)
Aux Return 22 k N/A -24 dBu +4 dBu +22 dBu Unbal. 1/4" Phono
(0 dB)
0 dBu = 0.775 V (RMS)
** Minimum input level (Sensitivity) is the smallest signal that will produce nominal output (+4 dBu) with sub and
master controls set for maximum gain.
* Nominal settings are defined as all controls set at 0 dB (or 50% rotation for rotary pots) except the gain
adjustment pot, which is as specified.
