17
3 inputs/6 outputs RTA Mic input can be summed with
Line inputs.
2 inputs/6 outputs LED STATUS:
Red = -0.5 dBFS and higher (Clip)
Red & Green = -4 to -0.5 dBFS
Green = -4 to -40 dBFS
Off = below -40 dBFS
Front panel switch and LED for each input and
output
LED STATUS:
Red = Muted
Off = On
-6 to +6 dB Software controlled
+24 dBu or -10 dBV Software selectable
4.4 k ohms Electronically balanced
24 dB
55 dB
-90 dB 20 Hz to 20 kHz
110 dB A-weighted 150 ohm input termination
+20 to +60 dB Approximately 1/2 dB steps
+2 dBu (.98Vrms) Gain = 60 dB, 22K BW
2.2 k ohm Electronically balanced
55 dB
-128 dB A-weighted 150 ohm input termination
+48 volts Software controlled
On XLR 1 Software selectable between left
channel analog line input
+24 dBu Balanced
150 ohms Electronically balanced
600 ohms Maximum output @ 600 ohms =
22.5 dBu
105 dB A-weighted
0.007 % 20 Hz to 20 kHz, 22 kHz BW filter,
+4 dBu signal with 20 dB headroom
20 Hz to 20 kHz ± 0.5 dBr referenced at 1 kHz
105 dB A-weighted, 150 ohm input
termination
< 1 mS Propagation delay from input to
output
