peerless-AV ESF655P - A ( 1 )

4
2014-09-24 #:203-9450-2 (2017-04-04)
1a-2
Level wallplate. Mark mounting holes on stud
center lines.
ENG
1a-1
Use stud nder to locate and
mark stud center lines.
ENG
8"
(20cm)
8"
(20cm)
5.35"
(136mm)
A
16"
(41cm)
