peerless-AV Neptune - Parts Identification

5
2020-09-02 #:204-9114-3 (2020-11-10)
Parts (Before beginning, make sure you have all parts shown below).
Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes).

ENG
ESP
FRN
D
(
4
)
8mm concrete anchor
E
(
4
)
#14 x 2-1/2" wood screw
A
(
1
)
wall plate
B (1)
right adaptor bracket
Parts List
Part #Description Qty
A wall plate 1 201-5946-1
B right adaptor bracket 1 202-5690
C left adaptor bracket 1 202-5687
D 8mm concrete anchor 4 590-0320
E #14 x 2-1/2" wood screw 4 521-1703
F M8 x 12mm 4 00000408
G M8 x 25mm 4 520-0667
H spacer 4 00000082
I 4mm allen wrench 1 560-1727
C (1)
left adaptor bracket
F
(
4
)
G
(
4
)
H
(
4
)
M8 x 12mm M8 x 25mm spacer
520-9571
I (1)
4mm allen
wrench
