3 of 34
ISSUED: 03-26-10 SHEET #: 095-9345-5 11-02-11
CDE FG
H
J
IL
A
Description Qty. Part #
wall arm assembly 1
095-P1990
B front cable cover 2 590-P1327
C wood screws 4 520-1202
D concrete anchors 4 590-0320
E
M10 x 5 mm socket head screw
2
520-9262
F
fastener caps
4
590-1324
G
cable ties
8
590-1168
H 6 mm allen wrench 1 560-9716
I 5 mm allen wrench 1 560-9640
J rear cable cover 2 590-P1326
#3 screwdriver bit 1 560-0209
L
5/32 allen wrench 1
560-9646
Parts List
B
K
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.
