PEERLESS SR560G - Parts List

3 of 13
ISSUED: 01-10-07 SHEET #: 009-9039-14 01-11-11
Before you begin, make sure all parts shown are included with your product.
Parts may appear slightly different than illustrated.
SR1M
SR560M
Description Qty. Part Number
Part Numbe
r
A
screen mount bracket 1 201-1156
201-1156
B
hook plate 1 201-1157
201-1157
C
shelf support 1 201-1158
201-1158
D
base 1 009-1223
009-1223
E
universal plate 1 N/A
201-1110
F
adapter bracket 2 N/A
201-1510
G
upright 1 580-1180
580-1180
H
top cover 1 590-1210
590-1210
I
1/4-20 x 12mm decorative screw 14 520-2325
520-2325
J
1/4-20mm nut 10 530-1050
530-1050
L 3/8-16 x 2.5" socket screw 3 520-9550 520-9550
M 7/32" allen wrench 1 560-9715 560-9715
N 4 mm allen wrench 1 560-9646 560-9646
O 8/32 nylock nut 6 530-1038 530-1038
P shelf pan 1 009-1225 009-1225
Q 6 mm allen wrench 1 560-9716 560-9716
R left leg 1 009-1296 009-1296
S right leg 1 009-1295 009-1295
T wheel caster 2 600-0044 600-0044
U wheel caster/brake 2 600-0045 600-0045
V
joint connector nut 4 530-1037 530-1037
W
3/8-16 x 1.5" screw bolt 4 520-1329 520-1329
X
M10 x .402 ID lock washer 3 540-9424 540-9424
Z
3/16 allen wrench
1 560-0071 560-0071
A
A
M4 x 12 mm serrated washer head socket pin scre
w
6 N/A 510-1079
BB M4 x 25 mm serrated washer head socket pin screw 4 N/A 510-1082
CC M5 x 12 mm socket pin screw 4 N/A 520-1064
DD M5 x 25 mm socket pin screw 4 N/A 520-1122
EE M6 x 12 mm socket pin screw 4 N/A 520-1050
FF M6 x 25 mm socket pin screw 4 N/A 520-1211
GG M8 x 15 mm socket button screw 6 N/A 520-1068
HH M8 x 40 mm socket pin screw 4 N/A 520-1152
II .219 ID x .5 OD x .5 HT spacer 4 N/A 540-1057
JJ .344 ID x .75 OD x .5 HT spacer 4 N/A 540-1059
KK universal plasma tilt multi washer 6 N/A 580-1036
LL M6 x 20 mm socket pin screw 4 N/A 520-9554
MM M6 x 30 mm socket pin screw 4 N/A 520-1067
NN M8 x 25 mm socket pin screw 4 N/A 520-1101
OO M10 x 15 mm socket scre
w
4 520-9262 520-9262
Parts List
