Page #17 background imageLoading...
Page #17 background image
15
BURNER SETUP & BOILER OPERATION
BECKETT BURNER SPECIFICATIONS
Boiler
Model No.
Burner
Model No.
Burner
Head
Static
Plate
Nozzle Size
Pump
Pressure
Start-up Settings
Head
Setting
Air Shutter Air Band
WBV-03-085 AFG-F3¹ F3 3-3/8" 0.75 80° B HAGO³ 140 PSI 6.0 1 N/A
WBV-03-105 AFG-F4 F4 3-3/8" 0.90 80° B HAGO 140 PSI 6.0 0 N/A
WBV-04-095 AFG-F4 F4 3-3/8" 0.85 80° B DEL
4
140 PSI 6.0 0 N/A
WBV-04-125 AFG-F4 F4 3-3/8" 1.10 80° B HAGO³ 140 PSI 5.0 2 N/A
WBV-04-150 AFG-F6 F6 2-3/4" 1.25 80° B HAGO 140 PSI 8.0 1 N/A
WV-05-175 AFG-MV1 V-1 - 1.50 60° B HAGO³ 140 PSI 10.0 3 3
WV-05-195 AFG-MV1 V-1 - 1.65 60° B HAGO 140 PSI 10.0 9 3
CARLIN BURNER SPECIFICATIONS (WITH 98022 PSC MOTOR)
Boiler
Model No.
Burner
Model No.
Head Bar Nozzle Size Pump Pressure
Start-up Settings
Air Shutter Air Band
WBV-03-085 EZ-1HP 0.60 - 0.65 0.65 70° A DEL³ 150 PSI Blank 0.60
WBV-03-105 EZ-1HP 0.85 - 1.00 0.85 70° A DEL 150 PSI Blank 0.65
WBV-04-095 EZ-1HP 0.75 0.75 70° A DEL
4
150 PSI Blank 0.60
WBV-04-125 EZ-1HP 0.85 - 1.00 1.00 70° A DEL³ 150 PSI Blank 0.85
WBV-04-150 EZ-1HP 1.10 - 1.25 1.25 60° B DEL 150 PSI Blank 1.00
WV-05-175 99FRD N/A 1.50 60° B HAGO³ 150 PSI Open 10% open
WV-05-195 99FRD N/A 1.65 60° B HAGO 150 PSI Open 45% open
RIELLO BURNER SPECIFICATIONS
Boiler
Model No.
Burner
Model No.
Burner Series Nozzle Size² Pump Pressure
Start-Up Settings
Turbulator Air Damper
WBV-03-060 F3 Series 40 0.50 90° B 145 PSI 0.0 2.9
WBV-03-085 F5 Series 40 0.65 60° W³ 170 PSI 1.0 2.45
WBV-03-105 F5 Series 40 0.85 60° W 165 PSI 2.5 2.8
WBV-04-095 F5 Series 40 0.75 80° B
4
160 PSI 0.5 2.25
WBV-04-125 F5 Series 40 1.00 60° W³ 155 PSI 2.5 3.4
WBV-04-140 F5 Series 40 1.10 60° W 160 PSI 4.0 4.2
WV-05-175 F10 Series 40 1.35 60° B³ 165 PSI 2.0 2.5
WV-05-195 F10 Series 40 1.50 60° B 170 PSI 2.5 2.8
Factory Installed Nozzles (Packaged Boilers or Burner Cartons) are indicated in Boldface.
1 Requires Low Firing Rate Baffle
2 Delavan Recommended
3 Shipped Loose with Packaged Boiler or Burner Carton
4 Not included with Packaged Boiler or Burner Carton
Table 5.1: Beckett Burner Specifications
Table 5.2: Carlin Burner Specifications (with 98022 PSC motor)
Table 5.3: Riello Burner Specifications
BECKETT NX BURNER SPECIFICATIONS
Boiler Model No. Burner Model Nozzle Size Pump Pressure Start Up Head/Air
WBV-03-085 NX70LB 0.65 x 60° W DEL³ 170 1.5
WBV-03-105 NX70LB
0.85 x 60° B HAGO
170 2.5
WBV-04-095 NX70LB 0.75 x 60° W DEL
4
170 2.0
WBV-04-125 NX70LD 1.10 x 60° W DEL³ 140 1.0
WBV-04-150 NX70LD 1.25 x 60° W DEL 140 2.0
Note: Burner used to fire the WBV-03-085 and 1.05 rate is also required to fire the WBV-04-095 rate with nozzle indicated in above chart.
