MANUALE D’USO – USER MANUAL
S9
Functioning setting set:
S9=0 ON-OFF
(Enabling ON between clamps 24 and 25)
S9=1 (INTEGRATED HUMIDOSTAT)
PROPORTIONAL WITH 4-20mA PROBE.
Functioning with integrated humidostat. Ambient humidity
probe 4-20mA connected to analogical input n.1 (clamps
14-15).
S9=2 PROPORTIONAL REFERRED TO 0-10V
EXTERNAL SIGNAL
Signal of reference 0-10V connected to analogical input
n.2 (clamps 16-17).
S9=3 (INTEGRATED HUMIDOSTAT)
PROPORTIONAL WITH 4-20mA PROBE AND
MAXIMUM LIMIT IN CHANNEL 4-20mA PROBE.
Ambient humidity probe 4-20mA connected to analogical
input n.1 (clamps 14-15).
Maximum limit in channel 4-20mA probe connected to
analogical input n.4 (clamps 21-22).
S9=4 PROPORTIONAL REFERRED TO 0-10V
SIGNAL AND MAXIMUM LIMIT IN CHANNEL 4-
20mA PROBE.
Signal of reference 0-10V connected to analogical input
n.2 (clamps 16-17).
Maximum limit in channel 4-20mA probe connected to
analogical input n.4 (clamps 21-22).
S9=5 (INTEGRATED HUMIDOSTAT)
PROPORTIONAL WITH 0-10V PROBE
Ambient humidity probe 0-10V connected to analogical
input n.2 (clamps 16-17).
S9=6 (INTEGRATED HUMIDOSTAT)
PROPORTIONAL WITH 0-10V PROBE AND
MAXIMUM LIMIT IN CHANNEL 0- 10V
PROBE.
Ambient humidity probe 0-10V connected to analogical
input n.2 (clamps 16-17).
Maximum limit in channel 0-10V probe connected to
analogical input n.5 (clamps 22-23).
S9=7 (INTEGRATED THERMOSTAT)
Functioning with integrated thermostat (hot call ON/OFF)
and NTC temperature probe connected to analogical input
n.3 (clamps 18-19).
S9=8 PROPORTIONAL REFERRED TO VALUE
SENT ON RS485 (0-100%)
Steam output request reference (0-100%) from RS485 line
(Modbus). To set steam output, use register 1537 .
N.B. The steam output and discharge force controls
envision a 1 minute time-out; if, during this period, the
control is not sent again, upon expiring of this time,
steam output will be placed at zero and the discharge pump
will be disabled. This places the humidifier in safe
conditions in case of accidental disconnections of the
network.
Attention: enabling between clamps 24 and 25 must be
given for any chosen type of functioning.
0 ÷ 8
0
0
0
0
S10
Discharge Test
0= Disabled
1= Enabled
0 ÷ 1
1
1
1
1
CA1
Humidity probe calibration
(used when S9=1, 3, 5, 6)
-20 % ÷ 20 %
0 %
0 %
0 %
0 %
CA2
Channel humidity probe calibration
(used when S9=3, 4, 6)
-20 % ÷ 20 %
0 %
0 %
0 %
0 %
