Pego EASYSTEAM User Manual

Rev. 01-16 Page 37
MANUALE D’USO – USER MANUAL
CA3
NTC probe value correction
(used when S9=7)
-10.0÷ 10.0 °C
0,0
0,0
0,0
0,0
t1
Delay in seconds to humidifier re-start. Delay starts
from when after the exceeding of StC by the humidity in
channel, it drops below StC-r0 again. Only after this delay
will normal functioning start again.
(used when S9=3, 4, 6)
0-240 s
10 s
10 s
10 s
10 s
t2
Functioning time ON for essence.
If steam output is present and temperature is above 70% of
SET set, the relay configured for essence call does so for
the t2 time and awaits the t3 time between one call and
another.
(used only when S9=7)
1-30 s
2 s
2 s
2 s
2 s
t3
Functioning time OFF for essence.
If steam output is present and temperature is above 70% of
SET set, the relay configured for essence call does so for
the t2 time and awaits the t3 time between one call and
another.
Con t3=0 continuous essence call is had if the above
conditions are satisfied.
(used only when S9=7)
0-99 min
5
min
5
min
5
min
5
min
t4
Timer for manual insertion outlet fans.
Manually activated function with arrow up+Stand-by
combination keys and active only with S9=7, dO4 or dO5=
-3 and humidifier in stand-by.
Once the plant is placed in stand-by at the end of the day,
there is the possibility of functioning the outlet fans for a
certain time to dry the room.
0-24 hours
0=Disabled
0
0
0
0
t5
Activation time E9 serious Alarm .
If the E8 alarm continues for a time longer than t5, starts
the E9 serious alarm.
E9 serious alarm starts also if in the space of 12 hours
occur 3 alarm E8 situations.
E9 alarm is disabled with t5=0.
0-99 min
0= Disabled
15
min
15
min
15
min
15
min
In1
Digital input In1 and activation status setting.
±10= drain pump driving
±9= functioning reduced to 90%
±8= functioning reduced to 80%
±7= functioning reduced to 70%
±6= functioning reduced to 60%
±5= functioning reduced to 50%
±4= functioning reduced to 40%
±3= functioning reduced to 30%
±2= Enabling (in series with eventual In2 and In3
enabling)
±1= alarm input
0= disabling
“+” for active input with close contact
“-“ for active input with open contact
-10 ÷ 10
2
2
2
2
In2
Digital input In2 and activation status setting.
See In1 options
-10 ÷ 10
10
10
10
10
In3
POWERED input In3 and activation status setting.
See In1 options
-10 ÷ 10
0
0
0
0
