ASSEMBLY
Unpack your heater, take out the foam from the bottom inside the box and find the
wheel base assemblies from this foam. Refer to Fig. below:
1. Make sure the heater is unplugged and
the power switch is in the “OFF”
position.
2. TURN THE HEATER UPSIDE
DOWN.
3. Position the wheel holding plate
between the last two fins as shown.
4. Insert the U-shape screw into the holes
of wheel holding plate.
5. Insert the butterfly nuts and tight them
securely.
6. Attached another wheel holding plate
next
to metal control box.
7. TURN THE HEATER UPRIGHT.
Your heater is now ready to use.
Risk of fire – Do not operate heater without wheel assemblies attached.
Operate heater in upright position only (wheels on bottom, controls on top). Any
other position could create a hazardous situation.
ELECTRICAL RATINGS
This product is rated 12.5 am
TURES
icator Light – It will illuminate when
ol – To set the comfort
itch –
s at
600 Watts of heat output
heater operates at
900 Watts of heat output
e heater operates at
1500 Watts of heat output
ps (1500W) at 120V, 60 Hz.
FEA
B
C
A
A Power Ind
heater is plugged in and the Power Switch is on LOW,
MED or HIGH position.
B Thermostat Contr
temperature.
C Power Sw
1) LOW: The heater operate
operation
.
2) MED:
The
operation
.
3) HIGH:
Th
operation
.
4
THERMOSTAT
Wheel holding
plate
Metal control box
Buerfly nuts
