REGULATORY INFORMATION
The dental chair is used to position the patient so that the oral cavity is in the desired position for the dentist to perform
various dental procedures. Dental chairs can be either hydraulically or electromechanically operated. There are two
dynamic functions: the base (up/down) and the back (incline/recline). These functions are activated by use of either a
footswitch or a hand-operated touch pad.
The dental chairs have the provision to mount additional dental equipment including over-the-patient delivery systems.
For this purpose the chair must provide a stable foundation for both the patient and the additional equipment.
Power to the chair is either 115 or 230 volts. The power is delivered to a microprocessor controlled printed circuit board.
Software in the microprocessor controls the movement of the chair. The dentist can program some chair models to preset
positions.
The dental chair is classied as a Class I device per FDA CFR 21, Health Canada, and under rule 1 of
Annex IX of the MDD 93/42/EEC.
Technical Description
Product Identication
This dental chair can be identied by its product label, located inside or underneath the chair seat. This label states the
chair model and serial number, electrical specications, manufacture date and safety classication. Note the SAMPLE
labels shown below.
RISK OF EXPLOSION IF USED
IN THE PRESENCE OF
FLAMMABLE ANESTHETICS.
ELECTRIC SHOCK HAZARD.
DO NOT REMOVE COVER.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
047R024 R8
WARNING:
ATTENTION!
THIS DEVICE SHOULD ONLYBE CONNECTEDTO HOSPITAL
GRADE OUTLETS. FAILURE TO DO SO MAYRESULTIN
ELECTRICAL SHOCK DUE TO IMPROPER GROUNDING.
CET APPAREIL DOIT ETRE BRANCHÉ AUNE PRISE DE
TERRE ADEQUATE.
70-22090 • Rev. 5•1/11
¡ADVERTENCIA!
ESTE DISPOSITIVO DEBE CONECTARSE ÚNICAMENTE A
TOMACORRIENTES DE GRADO HOSPITALARIO. SI NO SE HACE
ASÍ, PUEDE PRODUCIRSE UN CHOQUE ELÉCTRICO A CAUSA
DE UNA PUESTAATIERRA INADECUADA.
MN
SN
MO
YR
IECType B, Class 1, IPX4
Operation Mode:Intermittent
DENTAL CHAIR
052735 Rev 0, 10/06
SP
30
(230 VAC, 50/60 Hz
. 3.5
A)
34488
C
US
C
Certifed to: CAN/CSA- C22.2 NO. 601.1
Certified to UL 60601-1EN 60601-1
MN
SN
MO
YR
IECType B, Class 1, IPX4
Operation Mode:Intermittent
DENTAL CHAIR
Certifed to: CAN/CSA- C22.2 NO. 601.1
052736 Rev 0, 10/06
SP18
(115 VAC, 50/60 Hz. 7A)
34488
C
US
C
Certified to EN 60601-1 UL 60601-1
046820 Rev
. 3 02/11
Charlotte NC, U.S.A.28273,
11727 Fruehauf Dr.
046820 Rev
. 3 02/11
Charlotte NC, U.S.A.28273,
11727 Fruehauf Dr.
