PendoTECH PressureMAT PMAT4A - Keypad Functions and System Operation

PressureMAT User Guide
Revision 8
Page 14/48
Keypad
KEY Function
HOME/START
Dual Purpose:
1- Used to return to the HOME screen from the
program menus
2- Used to power on the system if turned off
STOP
Used to reset alarms (if optional alarm latching
turned ON)
TARE/LEFT ARROW
Dual Purpose:
1- Used when in the program menu to scroll
the cursor left
2- Zero pressure sensor of selected channel
when on the HOME screen
RIGHT ARROW/ALT
Used when in the program menu to scroll the cursor
right
UP ARROW
Three Purposes:
1- When on the HOME screen used to select
different input channels
2- In the program menus, used to select
different sub-menus
3- Within a program menu, used to change a
selected value
DOWN ARROW
Three Purposes:
1- When on the HOME screen used to select
different input channels
2- In the program menus, used to select
different sub-menus
3- Within a program menu, used to change a
selected value
SELECT/PROG
Used to enter the program menu for the selected
channel or for the selected menu; used to confirm
and save changes to a setting
BACK
Dual Purpose:
1- Used to return to the previous screen when
in a program menu
2- Can be pressed three times to access the
GLOBAL SETTINGS menu
