PressureMAT User Guide
Revision 8
Page 20/48
Global Settings Menu
The Global Settings menu can be used to program settings for the system that impacts all
channels; turn ON or OFF features, or view system information. To access the Global
Settings menu press the BACK button three times in rapid succession. The following screen
appears:
GLOBAL SETTINGS
> Information
System Power
Control Service
Communication
Date and Time
Note: Date and Time not present in S model
At this screen the UP/DOWN arrows are used to select the Global Setting. HOME/START
can be pressed at any time to return to the HOME screen.
Information
If SELECT/PROG button pressed, system information including firmware version is displayed.
Press the BACK button to return to the main menu.
System Power
If SELECT/PROG button pressed, the system power is removed. Press the HOME/START to
restore power.
Control Service
If SELECT/PROG button pressed, the following sub-menu appears with the following default
settings:
CONTROL SERVICE
> PV Decimal Off
Pressure Normal
Alarm Latch Off
Backlight High
Audio Beep On
Keypad Secure Off
Note: On model S, Pressure and Backlight not shown
At this screen the UP/DOWN arrows are used to select the Control Service setting.
PV Decimal
If turned on, the 2
nd
decimal place is shown. If off only one decimal place is shown. In the HR
models, this will enable the 3
rd
decimal.
