12 P545 Series Electronic Lube Oil Control Product/Technical Bulletin
Table 5: Wiring Harnesses and Other Accessories Ordering Information
Product Code
Description
CST29A-600C Sensor Block (for Carlyle Compressor Series O6CC, O6D, and O6E);
includes Allen-head bolts*.
P545NCB-82 Electronic Lube Oil Control;
includes P400AD-1C switch and WHA-P400-100C wire harness
3 1/3 ft (1 m) length wiring harness
4 ft (1 1/4 m) length wiring harness
8 ft (2 1/2 m) length wiring harness
14 ft (4 1/3 m) length wiring harness
Low-Voltage Current Sensing Switch
Universal Mounting Bracket
* Contact Carlyle Compressor Co. at (800) 462-2759 to order Sensor Block Gasket 06DA680063.
Repair and Replacement
Do not attempt field repairs or calibration. Switches,
alternate length wiring harnesses, and replacement
controls are available as separate items through local
Johnson Controls wholesalers and the original
equipment manufacturer.
