Pepperl+Fuchs Ecom Smart-Ex 02 - Page 15

15
Step 3
Insert the battery into the
battery
slot in the prescribed
order as
shown in the illustration
on the right.
Step 4
Reattach the battery
cover and screw down the
two cover
screws in a clockwise
direction.
Please use the
screwdriver Torx
T8 and ensure not to
overtighten the screws.
STEP 2
STEP 1
Getting Started
