Pepperl+Fuchs HiD2022 Series User Manual

2017-09
10
Functional Safety HiD2022*, KFD2-STC5-(Ex)*, KFD2-STV5-(Ex)*
Product Description
KFD2-STV5-1-1, KFD2-STV5-2-1
This signal conditioner provides the galvanic isolation between field circuits and
control circuits.
The device supplies 2-wire and 3-wire SMART transmitters, and can also be used
with 2-wire SMART current sources.
It transfers the analog input signal as an isolated current value.
Digital signals may be superimposed on the input signal on the field side or on the
control side and are transferred bi-directionally.
If the HART communication resistance in the loop is too low, the internal
resistance can be used.
Test sockets for the connection of HART communicators are integrated into the
terminals of the device.
The device is mounted on a 35 mm DIN mounting rail according to EN 60715.
KFD2-STV5-Ex1-1, KFD2-STV5-Ex2-1
This isolated barrier is used for intrinsic safety applications.
The device supplies 2-wire and 3-wire SMART transmitters, and can also be used
with 2-wire SMART current sources.
It transfers the analog input signal to the safe area as an isolated current value.
Digital signals may be superimposed on the input signal in the hazardous or non-
hazardous area and are transferred bi-directionally.
If the HART communication resistance in the loop is too low, the internal
resistance can be used.
Test sockets for the connection of HART communicators are integrated into the
terminals of the device.
The device is mounted on a 35 mm DIN mounting rail according to EN 60715.
