DOCT-0187Y 2023-12
18
K-System – Isolated Barriers
Product Specifications
Keypad and LC display
Via keypad you can configure the settings of the device parameters. Measured values,
fault signals and configuration settings are displayed on the LC display.
Figure 2.19
Programming sockets for the connection of a PC with parameterization software
PACTware
TM
Via parameterization software PACTware
TM
you can configure the device easily.
The configuration data can be edited and saved. The parameterization software helps users
for maintenance, diagnostics and troubleshooting.
Figure 2.20
1 LC display
2 Keypad
1 Programming socket
ESC
OK
21
Note
See manual HART Multiplexer System KFD*-HM*-16 for further information
for communication via software.
Note
See corresponding datasheets for further information.
