Perfomance Tool W50014 - Grease Gun Operation

To Convert The Gun To Allow Filling From Bulk Container Or Filler Pump
1. Unscrew the grease tube assembly cap from the grease tube assembly. Pull on the
follower handle to extract the follower and spring from the grease tube assembly.
2. Graspthefollowerbetweenyourthumbandforengerandipthefollowerlipfromthe
rear to the front side.
NOTE: The follower resembles a cup. When the gun is assembled for use with bulk
lubricant, the cup opens toward the pump assembly.
3. Reassemble the follower into the grease tube assembly and position with the follower
handle so that the grease tube assembly cap can be tightened onto the container tube.
To Fill The Gun From A Bulk Container
1. Rotate the grease tube assembly counterclockwise to unscrew the grease tube
assembly from the gun.
2. Insert the open end of the grease tube assembly into the lubricant. Slowly pull the
follower handle back while pushing the grease tube assembly deeper into the lubricant to
prevent air pockets from being pulled into the grease tube assembly.
3. When the follower rod is fully extended (approximately 8 in. or 20 cm), the grease tube
assembly is full. Release the follower key to hold the follower rod in its extended position.
4. Screw the grease tube assembly clockwise into the gun. To release the follower rod,
depress the follower key and push the follower rod forward into the grease tube assembly.
Purge the air from the pump. See the section To Re-prime.
5. Clean any excess grease from the gun body.
To Fill The Gun With A Filler Pump
Abulkllertting(soldseparately)willneedtobeinstalledinthegreasegunheadcap.
Replacethepipeplugintheheadcapwiththebulkloadertting.Engagethefollowerrod
withthefollowerbyrotatingthefollowerhandle.Insertthegunllernippleintothell
pumpsocket.Operatethellerpumptollthecontainer.Whenthefollowerrodgrooveis
exposed,thegreasetubeassemblyislled.Thefollowerrodwillbeextended
approximately 8 inches (20 cm). Disengage the follower rod from the follower by rotating
the follower handle. Push the follower rod into the grease tube assembly.
1. Fully insert the charged battery pack into the grease gun.
2. Connectthehigh-pressurehosecouplertothegreasetting,andensurethatthe
couplerissquarelyseatedonthetting.
3. Squeeze the trigger switch to activate the grease gun. Grease should now be
dispensedthroughthehigh-pressurehosecouplerandintothegreasetting.
4. Whenyouhavenishedapplyinggrease,removethehigh-pressurehosecouplerfrom
thegreasettingbypullingitsideways.
WARNING! Do not adjust the pressure relief valve. If backpressure in the high-pressure
hoseexceedsthefactory’spresetpressurerating,greasewillbedischargedthroughthe
pressure relief valve to prevent motor overload and to limit grease pressure within the hose.
Removing Empty Grease Cartridge
1. Pull back on the follower handle until the follower rod is fully extended and latch the
follower rod groove into the slot on the tube end cap of the grease tube.
NOTE: It may be necessary to loosen the grease tube assembly in order to break the
vacuum seal.
2. Rotate the grease tube assembly counterclockwise to unscrew the grease tube
assembly from the gun.
3. Carefully release the follower handle to eject the empty cartridge from the container tube.
TOOL USE AND CARE CONT.
OPERATION
6
