Contents
I - Parts list A/1
II - Technical data 1
III - Safety instructions 2
IV - Getting started 5
V - Operation 7
VI - Maintenance and repair 8
VII - Guarantee 10
I - Parts list
1. Saw arm
2. Release knob
3. Operating handle
4. Upper fixed blade guard
5. Rotating blade guard
6. Guard retraction arm
7. Bevel lock
8. Bevel scale
9. 45° Bevel adjustment screw
10. 0° Bevel adjustment screw
11. Fence
12. Mitre table
13. Mitre scale
14. Table insert (kerf plate)
15. Mitre lock (x 2)
16. Switch trigger
17. Release latch
18. Spindle lock button
19. Blade bolt cover
20. 6mm Hex key
21. Dust extraction port
22. Dust extraction port cover
23. Dust bag
II - Technical data
Voltage: ............................... 230–240V ~ 50 Hz
Power input: ....................... 1400W
No load speed: .................. 5000min
-1
Blade diameter: ................. 210mm
Blade bore: ......................... 30mm
Blade teeth: ........................ 24 TCT
Maximum depth of cut: ..... 55mm
Blade thickness: ................ 2.5mm
Mitre table angles: ............. 0° to 45° to the
left & right
Bevel cuts: .......................... 0° to 45° to the left
Cutting capacities:
Straight cut at 0° x 0° ........ 120mm x 55mm
Miter cut at 45° x 0° ........... 83mm x 55mm
Bevel cut at 0° x 45° .......... 120mm x 30mm
Compound mitre cut
at 45° x 45°: ........................ 83mm x 30mm
Net weight: ......................... 6.1kg
Connector for dust
extractor: ............................ 47mm external
diameter for dust
bag, 40mm internal
diameter for dust
extractor
Insulation class: ................. Double insulated
NOISE AND VIBRATION DATA
A weighted sound pressure: ......... 97 dB(A)
A weighted sound power: .............. 110 dB(A)
Typical weighted vibration: ............ 2.4m/s
2
The sound intensity level for the operator
may exceed 85dB(A) and sound protection
measures are necessary.
