Portable, fast, and very simple to use battery starting and charging system analyzer.
Digital display indicates the condition of your battery and charging system.
Tests 12VDC systems, guiding you through the testing process.
Clear and easy to understand results to indicate systems condition.
Battery CCAs: 200-1200 Battery Types: LA, AGM, and VRLA
Voltage: 7-15VDC Testing Standards: SAE, DIN, EN, IEC, and CA
1. Correctly connect the clamps to the vehicle battery.
2. Tester will default to the battery test display.
3. Press right arrow button three times, LCD BRIGHTNESS will display.
4. Press enter button, LCD Brightness in percentage will display.
5. Press the right or left arrow button to adjust the LCD brightness percent.
6. Press enter to save the setting.
1. Maintain a safe working environment. Keep the work area well lit. Make sure there is
adequate surrounding workspace. Always keep the work area free of obstructions, grease, oil,
trash, and other debris.
2. Maintain labels and nameplates on this product. These carry important information. If
unreadable or missing, contact Performance Tool for a replacement.
3. Be alert for hot engine parts to avoid accidental burns.
4.
Avoid accidental re and/or explosion. Do not smoke near engine fuel and battery components.
5. WARNING! The warnings, precautions, and instructions discussed in this manual cannot
cover all possible conditions and situations that may occur. The operator must understand that
common sense and caution are factors which cannot be built into this product, but must be
supplied by the operator.
6. Working near lead acid batteries can be dangerous, they produce explosive gases. To
reduce risk, follow the manufacture instruction on handling the battery.
7. Avoid the risk of contact, battery uid is a highly corrosive sulfuric acid and WILL burn.
8. You must be sure the area is well ventilated while the battery is being tested.
Determine Battery Type:
REGULAR LIQUID – Lead Acid
AGM BATTERY – Absorbing Glass Mat
VRLA BATTERY – Vent Regulating Lead Acid
Determine Battery Rating: SAE DIN IEC EN or CA (MCA)
SAE: United States Standard
EN: European Standard
DIN: German Standard
IEC: International electrical science and technology association
CA (MCA): Normal starting current or maritime starting current
DISPLAY ADJUSTMENT
2
7
DESCRIPTION
PRIOR TO BATTERY TEST
SAFETY RULES
Testing Range: Rating Standard.
SAE: 40 1200CCA
EN: 40 1150CCA
DIN: 25 675CCA
IEC: 30 775CCA
