IMPORTANT SAFETY INFORMATION
WARNING: The use of any accessory or attachment other than one recommended in this
instruction manual may present a risk of personal injury.
WARNING:
The warnings, cautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be understood by the
operator that common sense and caution are factors which cannot be built into this product, but
must be supplied by the operator. Read and understand all of the instructions provided in the
instruction manual as well as any other tool (s) used with the roller support stand.
Use hex key provided.
1. Remove the pins from the leg assembly (3) and insert
the pins into the holes of the stand assembly (4) as
shown in Fig. 1. Connect the leg assembly and stand
assembly with the hex bolt as shown in Fig 2. Use
the hex key to tighten the hex bolt, make sure the leg
assembly is locked firmly as shown in Fig 3. Repeat
this step with the other leg assembly.
ASSEMBLY INSTRUCTIONS
PARTS DESCRIPTION
1. Roller Assembly
2. Height Adjustment Handle
3. Leg Assembly
4. Stand Assembly
5. Hex kex & Hardware
Fig. 1
1
2
3
4
5
Fig. 2
Fig. 3
3
To Next Page
