TECHNICAL SPECITFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Your digital PERFORMANCE TOOL caliper was constructed with quality
materials and workmanship and will give you many years of trouble free
use when cared for as described in the "Care & Maintenance" section.
1. Keep unit clean & free of dust / debris. Do not submerged or expose
to damp enviroments
2. LCD screen should be cleaned with a clean, dry, lint-free cloth.
Lubricate body with a few drops of lubrication oil. Do not use
Acetone or Alcohol.
3. Keep battery compartment clean & free corrosion.
Measures:
Outside, Inside,
Depth & Step
Outside Measurement Inside Measurement Depth / Step Measurement
3
Accuracy: ........................................................... 0.0005 in. (0.01mm)
Measuring system: ............................................ Non-contaction linear CAP
LCD Display:...................................................... .39 x 1.18 in. (10 x 30 mm)
Battery: .............................................................. AG13 (357A) 1.5V
Operating temperature: ..................................... 0 C ~ + 40° C
Storage temperature:......................................... -20 ~ +70 (0-80% Humidity)
Range: ............................................................... 0-6 (0-150 mm)
0 - 6" (0 - 150 mm)
0 - 8" (0 - 200 mm)
0 - 12" (0 - 300 mm)
0 - 20" (0 - 500 mm)
0 - 8" (0 - 200 mm)
0 - 12" (0 - 200 mm)
12" - 20" (300 - 500 mm)
0.0005" (0.01 mm)
0.0005" (0.01 mm)
0.0005" (0.01 mm)
0.0005" (0.01 mm)
0.001" (0.03 mm)
0.0015" (0.04 mm)
0.002" (0.05 mm)
Measuring Range:
Measuring Range:
Resolution:
Accuracy:
5. Thumb wheel
6. Battery compartment cover
7. Z ero but ton
8. On / Off button
9. Outside measuring faces
1. Inside measuring faces
2. SAE / Metric function
3. Lock screw
4. LCD Display
This instruction manual is intended for your benefit. Please read and follow the safety, installation, maintenance and troubleshooting
steps described within to ensure your safety and satisfaction. The contents of this instruction manual are based upon the latest
product information available at the time of publication. The manufacturer reserves the right to make product changes at any time
without notice.
WARNING: Read and understand this entire instruction manual before attempting to assemble, install, operate or maintain
this product. Failure to comply with the instructions may result in serious personal injury and/or property damage!
TOOL FEATURES SAFETY GUIDELINES / DEFINITIONS
SPECIFICATIONS
TECHNICAL SPECIFICATIONS
CARE AND MAINTENANCE
